ESD anti-static plastic storage tray for electronics. Static protective, scratch-proof, stackable and customizable.
This anti-static ESD plastic storage tray is engineered to eliminate static buildup and protect sensitive electronic components from electrostatic breakdown. Independent molded slots isolate parts to prevent scratching and mutual abrasion during storage and transportation. The rigid plastic body allows stable stacking to maximize warehouse space utilization, while custom sizes, cavity configurations and material grades are available to match diverse industrial electronic storage requirements.
- 1 Permanent & Stable ESD Protection
- 2 Precision CNC Tool-Molded Pockets
- 3 100K Cleanroom Certified Hygiene
- 4 High-Density Space-Saving Nesting
Anti static ESD plastic storage tray is part of our Thin-Gauge Precision Trays line. The series-level introduction, specifications, applications and FAQ below apply to this model and its related sizes. Custom specifications, materials and branding are available for bulk orders.
Product Overview & Market Intent
Semiconductor and consumer-electronics lines run anti static ESD where a component has to stay aligned through pick-and-place, conveyor transfer and container shipping. Tolerances are held tight enough that the tray substitutes directly for the existing handling hardware.
More than twenty years of OEM and ODM thermoforming sit behind the production of these trays, which are moulded in a 100,000-class dust-free area. We work in anti-static, dissipative and conductive PS, PET and PVC, holding micro-tolerances so the parts integrate with the equipment that handles them.
Key Product Characteristics
Permanent & Stable ESD Protection (Zero Electrostatic Risk): The anti-static properties are deeply embedded into the plastic sheet matrix, making sure long-term stable resistivity (10^6 – 10^9 Ohm for dissipative or 10^3 – 10^5 Ohm for conductive) that won’t fade due to friction, washing, or environmental humidity changes.
Precision CNC Tool-Molded Pockets: Utilizing high-precision CNC tooling, each pocket/cavity is engineered with precise draft angles and tolerances, making sure components stay snugly in place without friction damage while allowing rapid mechanical grabbing.
100K Cleanroom Certified Hygiene: Free from airborne dust, oils, or lint fibers, making sure that sensitive electronic sensors, lenses, and acoustic parts are protected from microscopic surface contamination.
High-Density Space-Saving Nesting: In the empty state, these thin-walled trays nest smoothly together with minimum clearance, considerably lowering warehouse storage footprint and reducing international ocean freight costs per unit.
On ESD-sensitive lines running anti static ESD, hardware & Fine Instrument Storage: Serves as precision custom-slotted storage inserts for multi-part toolkits, micro-screws, and calibration tools in assembly bays. Commercial Applications & Scenarios Automated PCBA & Semiconductor Shipping: Serves as the standardized carrying tray matrix for raw circuit boards, microchips, and motherboard modules passing through high-speed SMT assembly lines. Consumer Electronics & Earphone Inner Liners: Tailored sleek black or custom-colored thin-gauge blister inserts used inside retail packaging for high-end earphones, smartwatches, and smartphone accessories to boost shelf presence. Fragile Medical Electronics Components: Provides secure, clean-room approved compartmentalized tray packaging for precision laboratory sensors and dental equipment pieces.
Technical Specifications
Technical Detail & Industrial Standard: Product Category
ESD Blister Trays / Thin-Gauge Electronic Packaging / Vacuum Formed Inserts: Material Formulation
On ESD-sensitive lines running anti static ESD, high-Grade PS (Polystyrene), PET, PVC (Virgin Clear or Solid Matte Finishes): Material Thickness Range
Thin-Gauge Options: 0.5mm, 0.8mm, 1.0mm, to 1.5mm
Conductive: 10^3 – 10^5 Ohm | Dissipative: 10^6 – 10^9 \Ohm$ | Anti-Static: 10^9 – 10^{11} \Ome$
Production Environment: 100,000-Class Dust-Free Cleanroom Production Lines
Core Compliance: RoHS Compliant, REACH Certified, Lead-Free, SGS Laboratory Tested
Customization Capability: Full Custom CAD/3D Sample Engineering, Engraved Part Numbers & Logos
